MS 14050 RS

Артикул: MS 14050 RS

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CDX Cutting depth maximum

2 mm

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

39.12 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

50 mm

Delivery state valid from

1/16/2007

DHUB Hub diameter

45 mm

DIN

FDA02200200

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

"Metal Slash" face mill MS 1400 for steel and cast iron

GAMF Rake angle radial

10 Degree

GAMP Rake angle axial

-5 Degree

HAND Cutting direction

R - Right

ID Technical product number

MS 14050 RS

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

25 Degree

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

FDA Milling arbor mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0220

LOC-03 DCONMS Diameter

22 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02200200

Name Identifying order number

MS 14050 RS

OAL Overall length

40 mm

RMPX Ramping angle maximum

1.75 Degree

Working process

FPL - Face milling

WT Weight of item

0.3 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
