Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter GRC 6250 R-S

GRC 6250 R-S

Артикул: GRC 6250 R-S

В наличии

В корзину

Описание

Характеристики

BLDA Tool style code Position A

CCONMS Connection count machine side

CDX Cutting depth maximum

10 mm

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

250 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

265 mm

Delivery state valid from

1/16/2007

DHUB Hub diameter

130 mm

DIN

SPK06000200

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

30°-Planfräser mit extrem großem Spanwinkel für sc

GAMF Rake angle radial

10 Degree

GAMP Rake angle axial

25 Degree

HAND Cutting direction

R - Right

ID Technical product number

GRC 6250 R-S

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

SPK Spindle nose mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0600

LOC-03 DCONMS Diameter

60 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SPK06000200

Name Identifying order number

GRC 6250 R-S

OAL Overall length

63 mm

Working process

FPL - Face milling

WT Weight of item

11.3 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
