Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter F2146.B27.080.Z10.R599

F2146.B27.080.Z10.R599

F2146.B27.080.Z10.R599 F2146.B27.080.Z10.R599 F2146.B27.080.Z10.R599

F2146.B27.080.Z10.R599

Walter
Артикул: 5085053
В наличии
В корзину
Описание
Характеристики
BI Block index
1
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DAH Diameter access hole
20 mm
DC Cutting diameter
80 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
FDA02701200
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
10
FamilyProducts
Octagonal Finishing Face Mill F2146
HAND Cutting direction
R - Right
ID Technical product number
5085053
Interface codes
J6 / J61
ISO
FDA12G2700$$$$
ISYC Subclass
308-01 - Face milling cutter
KAPR Tool cutting edge angle
43 Degree
LOC-01 BI Block index
1
LOC-01 ISO
WR$$OP0504***N*****
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
W-OP0504**
LOC-03 CCFMS Form
12
LOC-03 CCSMS Style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Type
FDA Milling arbor mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0270
LOC-03 DCONMS Diameter
27 mm
LOC-03 ISO
FDA12G2700$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02701200
Name Identifying order number
F2146.B27.080.Z10.R599
OAL Overall length
50 mm
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
11200 1/min
Working process
FPL - Face milling
WT Weight of item
1.342 kg
ZEFF Face effective cutting edge count
10
ZEFP Peripheral effective cutting edge count
10
