Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter DAHM.37.040.A1635.05

DAHM.37.040.A1635.05

DAHM.37.040.A1635.05

DAHM.37.040.A1635.05

Paul Horn
Артикул: DAHM37040A163505
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
60 Degree
B1A Cutting edge length Pos. A
7.9 mm
BD Body diameter
39 mm
BLDA Tool style code Position A
99
CCONMS Connection count machine side
1
CDX Cutting depth maximum
1.2 mm
CICT Cutting item count
5
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HORN - Paul Horn
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
40 mm
DCCB Counterbore diameter connection bore
14 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/2/2013
DHUB Hub diameter
33 mm
DIN
FDA01600210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
Messerkopf zum Hochvorschubfräsen DAHM
HAND Cutting direction
R - Right
ID Technical product number
DAHM37040A163505
Interface codes
J6 /
ISYC Subclass
308-01 - Face milling cutter
LCCB Counterbore depth connection bore
25 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA01600210
Name Identifying order number
DAHM.37.040.A1635.05
OAL Overall length
35 mm
Working process
FPL - Face milling
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
