Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter 80A06RF60HN09C

80A06RF60HN09C

Артикул: 3114326

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CDX Cutting depth maximum

8 mm

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

80 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

89 mm

Delivery state valid from

1/4/2011

DIN

FDA02700200

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

HexaCut 60° Face Mills - Medium Pitch - Right Hand

HAND Cutting direction

R - Right

ID Technical product number

3114326

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

60 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0270

LOC-03 DCONMS Diameter

27 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02700200

Name Identifying order number

80A06RF60HN09C

OAL Overall length

50 mm

RPMX Rotational speed maximum

3900 1/min

Working process

FPL - Face milling

WT Weight of item

1.6 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
