Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter 4.38960R275

4.38960R275

Артикул: 4.38960R275

В наличии

В корзину

Описание

Характеристики

BD Body diameter

48 mm

BI Block index

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter

60 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

50 mm

Delivery state

LH - Stocked

DIN

KH-FWZ27

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

GROOVING END MILL

HAND Cutting direction

R - Right

ID Technical product number

4.38960R275

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

LOC-01 BI Block index

LOC-01-Connection-codes

J44 / J441 - Insert (Unknown 01)

LOC-01-DIN

KH-WP 684.6804

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CZCMS Connection size code

0270

LOC-03 DCONMS Diameter

27 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-FWZ27

Name Identifying order number

4.38960R275

OAL Overall length

42 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
