Главная Каталог продукции Toolunited 14 308-01 - Face milling cutter 4.00404R555

4.00404R555

Артикул: 4.00404R555

В наличии

В корзину

Описание

Характеристики

BD Body diameter

53 mm

BI Block index

CCONMS Connection count machine side

COMPC Company code

KH - Kennametal

DC Cutting diameter

40 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DHUB Hub diameter

33 mm

DIN

KH-FWPI R55516

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

FACE MILL 45° SEKX12M5

HAND Cutting direction

R - Right

ID Technical product number

4.00404R555

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

45 Degree

LOC-01 BI Block index

LOC-01-Connection-codes

J44 / J441 - Insert (Unknown 01)

LOC-01-DIN

KH-WP SCKX12M5

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-FWPI R55516

Name Identifying order number

4.00404R555

OAL Overall length

32 mm

Working process

No working processes available

WT Weight of item

0.3 kg

ZEFP Peripheral effective cutting edge count
