100B14LF45HN09C
100B14LF45HN09C
Артикул:
2016110
В наличии
Характеристики
A1A Cutting edge angle major Pos. A
120 Degree
A2A Clearance angle major Pos. A
0 Degree
B1A Cutting edge length Pos. A
9.17 mm
B2A Insert width Pos. A
15.88 mm
BLDA Tool style code Position A
8
C1A Insert thickness Pos. A
5.56 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
6.5 mm
CICT Cutting item count
14
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
100 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
113 mm
Delivery state valid from
12/1/2008
DIN
FDA03200200
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
14
FamilyProducts
HexaCut 45° Face Mills - Fine Pitch - Left Hand
HAND Cutting direction
L - Left
ID Technical product number
2016110
Interface codes
J6 /
ISYC Subclass
308-01 - Face milling cutter
KAPR Tool cutting edge angle
45 Degree
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA03200200
Name Identifying order number
100B14LF45HN09C
OAL Overall length
50 mm
RPMX Rotational speed maximum
3400 1/min
Working process
FPL - Face milling
WT Weight of item
2.3 kg
ZEFF Face effective cutting edge count
14
ZEFP Peripheral effective cutting edge count
14
