Главная Каталог продукции Toolunited 14 310-00 - Turning tool with carbide tips unspecified 270398 6,2

270398 6,2

Артикул: 270398 6,2

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

0.7 mm

COMPC Company code

HOG - Hoffmann Group

Delivery state valid from

1/11/2017

DIN

HOG-MICROT6

DMIN Minimum bore diameter

6.2 mm

EPSR Insert included angle

90 Degree

FamilyProducts

GARANT 45° turning/chamfering insert, internal left-hand

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

310-00 - Turning tool with carbide tips unspecified

LH Head length

28 mm

LOC-03 B Shank width

3.95 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HOG-MICROT6

Name Identifying order number

270398 6,2

OAL Overall length

67.2 mm

Working process

No working processes available

WT Weight of item

0.02 kg
