Главная Каталог продукции Toolunited 14 310-00 - Turning tool with carbide tips unspecified 270340 4,2/1

270340 4,2/1

Артикул: 270340 4,2/1

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

1 mm

COMPC Company code

HOG - Hoffmann Group

Delivery state valid from

1/11/2017

DIN

HOG-MICROT4

DMIN Minimum bore diameter

3.95 mm

EPSR Insert included angle

4 Degree

FamilyProducts

GARANT Grooving insert, internal round, left-hand

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

310-00 - Turning tool with carbide tips unspecified

LH Head length

18.4 mm

LOC-03 B Shank width

3 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0040

LOC-03 DCONMS Diameter

4 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HOG-MICROT4

Name Identifying order number

270340 4,2/1

OAL Overall length

48.8 mm

Working process

No working processes available

WT Weight of item

0.009 kg
