270090 8/1,5

Артикул: 270090 8/1,5

В наличии

В корзину

Описание

Характеристики

COMPC Company code

HOG - Hoffmann Group

Delivery state valid from

1/11/2017

DMIN Minimum bore diameter

9.6 mm

EPSR Insert included angle

8.3 Degree

FamilyProducts

GARANT Mini indexable insert for internal grooving, right-ha

HAND Cutting direction

R - Right

Interface codes

ISYC Subclass

310-00 - Turning tool with carbide tips unspecified

LH Head length

3.45 mm

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

Name Identifying order number

270090 8/1,5

OAL Overall length

4.44 mm

WF Functional width

4.8 mm

Working process

No working processes available

WT Weight of item

0.003 kg
