Главная Каталог продукции Toolunited 14 309-09 - System tool for internal turning 12631128200

12631128200

12631128200

Widia

Артикул: 12631128200

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

0 Degree

B3A Inscribed circle diameter Pos. A

9.525 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

4.76 mm

CEATC Tool cutting edge angle type code

E - Front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCC Design configuration style code

A - Solid steel, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

228 €

DHD Drop head design

2 - Normal and overhead

DIN

UTS03200195

DIN CSW1

DN1104 2N

DMIN Minimum bore diameter

32 mm

EPSR Insert included angle

55 Degree

FamilyProducts

Cutting head for internal turning

GAMO Rake angle orthogonal

-6 Degree

HAND Cutting direction

R - Right

HF Functional height

16 mm

ID Technical product number

12631128200

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-09 - System tool for internal turning

KAPR Tool cutting edge angle

93 Degree

L Cutting edge length

11.6 mm

LF Functional length

90 mm

LH Head length

75 mm

LOC-03 CCFMS Form

01

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

UTS Widaflex connection WIDIA

LOC-03 CCUMS Unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

UTS03200195

LPR Protruding length

90 mm

LTA Length tool assembly

90 mm

MTP Clamping type code

P - Hole clamping, with straight bore

Name Identifying order number

12631128200

OAL Overall length

90 mm

STDDES Standard designation

A32G-PDUNR11

THSC Tool holder shape code

A - offset shank design

WF Functional width

17 mm

Working process

DDB - External and internal turning
