Главная Каталог продукции Toolunited 14 309-09 - System tool for internal turning 12630120500

12630120500

12630120500 12630120500

12630120500

Widia
Артикул: 12630120500
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
7 Degree
B3A Inscribed circle diameter Pos. A
9.525 mm
BLDA Tool style code Position A
3
C1A Insert thickness Pos. A
3.97 mm
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
WI - Widia
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCC Design configuration style code
A - Solid steel, with internal coolant supply
DCP Data chip provision
0 - Without data chip
Delivery state valid from
216.5 €
DHD Drop head design
2 - Normal and overhead
DIN
UTS03200195
DIN CSW1
DC11T3 3N
DMIN Minimum bore diameter
25 mm
EPSR Insert included angle
55 Degree
FamilyProducts
Cutting head for internal turning
GAMF Rake angle radial
0 Degree
GAMO Rake angle orthogonal
0 Degree
HAND Cutting direction
L - Left
HF Functional height
16 mm
ID Technical product number
12630120500
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-09 - System tool for internal turning
KAPR Tool cutting edge angle
93 Degree
L Cutting edge length
11.6 mm
LAMS Inclination angle
0 Degree
LH Head length
40 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
UTS Widaflex connection WIDIA
LOC-03 CCUMS Unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
UTS03200195
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
12630120500
OAL Overall length
55 mm
STDDES Standard designation
A32C-SDUCL11
THSC Tool holder shape code
A - offset shank design
WF Functional width
13 mm
Working process
DDB - External and internal turning
