Главная Каталог продукции СЗЦПК инструмент 14 309-08 - System tool for external threading KM50S20HLSER16

KM50S20HLSER16

KM50S20HLSER16 KM50S20HLSER16

KM50S20HLSER16

Kennametal
Артикул: 1020522
В наличии
В корзину
Описание
Характеристики
CEDC Cutting edge count
1
COMPC Company code
KH - Kennametal
DCC Design configuration style code
S - Solid steel, no construction features
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
KH-KMCI LSEKM50
DMIN Minimum bore diameter
25 mm
FamilyProducts
KM BORING BAR THREADING LSE
HAND Cutting direction
R - Right
ID Technical product number
1020522
Interface codes
J6 /
ISYC Subclass
309-08 - System tool for external threading
KAPR Tool cutting edge angle
90 Degree
LAMS Inclination angle
15 Degree
LH Head length
70 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
KMT KM connection KENNAMETAL / UTS connection WIDIA
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
KH-KMCI LSEKM50
MTP Clamping type code
P - Hole clamping, with straight bore
Name Identifying order number
KM50S20HLSER16
OAL Overall length
100 mm
WF Functional width
13 mm
Working process
No working processes available
