Главная Каталог продукции Toolunited 14 309-11 - System tool for OD grooving and parting R368.2608.11

R368.2608.11

Артикул: R368260811

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

8 mm

CEDC Cutting edge count

COMPC Company code

HORN - Paul Horn

CW Cutting width

1.5 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/2/2013

DIN

VKT26080105

DIN CSW1

HORN-31201

FamilyProducts

Toolholder

HAND Cutting direction

R - Right

HF Functional height

21.4 mm

ID Technical product number

R368260811

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-11 - System tool for OD grooving and parting

LF Functional length

110 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT26080105

LPR Protruding length

110 mm

LTA Length tool assembly

110 mm

Name Identifying order number

R368.2608.11

OAL Overall length

110 mm

WF Functional width

1.3 mm

Working process

No working processes available
