Главная Каталог продукции Toolunited 14 309-11 - System tool for OD grooving and parting R368.1616.08

R368.1616.08

Артикул: R368161608

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

8 mm

CEDC Cutting edge count

COMPC Company code

HORN - Paul Horn

CW Cutting width

1.9 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/2/2013

DIN

VKT16160105

DIN CSW1

HORN-31201

FamilyProducts

Toolholder

HAND Cutting direction

R - Right

HF Functional height

24 mm

ID Technical product number

R368161608

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-11 - System tool for OD grooving and parting

LF Functional length

95 mm

LH Head length

19.5 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

1616

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT16160105

LPR Protruding length

19.5 mm

LTA Length tool assembly

95 mm

Name Identifying order number

R368.1616.08

OAL Overall length

95 mm

WF Functional width

1 mm

Working process

No working processes available
