Главная Каталог продукции Toolunited 14 309-11 - System tool for OD grooving and parting R360.TS63.K3

R360.TS63.K3

Артикул: R360TS63K3

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

6 mm

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HORN - Paul Horn

CW Cutting width

3.9 mm

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/15/2014

DIN

HORN-TS463

DIN CSW1

HORN-31203

FamilyProducts

312 Insert

HAND Cutting direction

R - Right

HF Functional height

31.5 mm

ID Technical product number

R360TS63K3

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-11 - System tool for OD grooving and parting

LF Functional length

50 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0300

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HORN-TS463

LPR Protruding length

31 mm

LTA Length tool assembly

50 mm

Name Identifying order number

R360.TS63.K3

OAL Overall length

50 mm

WF Functional width

28.5 mm

Working process

DEA - Outer diameter grooving
