Главная Каталог продукции СЗЦПК инструмент 14 309-07 - System tool for external turning KM40PSRNL12

KM40PSRNL12

Артикул: 1670418

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

COMPC Company code

KH - Kennametal

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

KMT04000185

FamilyProducts

KM CUTTING UNIT P-CLAMPING PSR

HAND Cutting direction

L - Left

ID Technical product number

1670418

Interface codes

J6 /

ISYC Subclass

309-07 - System tool for external turning

KAPR Tool cutting edge angle

75 Degree

L Cutting edge length

12.7 mm

LAMS Inclination angle

5 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KMT04000185

MTP Clamping type code

P - Hole clamping, with straight bore

Name Identifying order number

KM40PSRNL12

OAL Overall length

40 mm

WF Functional width

24 mm

Working process

No working processes available
