12631230386
12631230386
Артикул:
12631230386
В наличии
Характеристики
A2A Clearance angle major Pos. A
0 Degree
B3A Inscribed circle diameter Pos. A
9.525 mm
BLDA Tool style code Position A
3
C1A Insert thickness Pos. A
4.76 mm
CEATC Tool cutting edge angle type code
S - Side lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
WI - Widia
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCC Design configuration style code
A - Solid steel, with internal coolant supply
DCP Data chip provision
0 - Without data chip
Delivery state valid from
163.3 €
DHD Drop head design
2 - Normal and overhead
DIN
UTS04000195
DIN CSW1
DN1104 2N
EPSR Insert included angle
55 Degree
FamilyProducts
Cutting head for external turning
GAMF Rake angle radial
-6.356 Degree
GAMO Rake angle orthogonal
-6 Degree
HAND Cutting direction
L - Left
HF Functional height
20 mm
ID Technical product number
12631230386
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-07 - System tool for external turning
KAPR Tool cutting edge angle
93 Degree
L Cutting edge length
11.6 mm
LAMS Inclination angle
-7 Degree
LF Functional length
40 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
UTS Widaflex connection WIDIA
LOC-03 CCUMS Unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Size code
0400
LOC-03 DCONMS Diameter
40 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
UTS04000195
LPR Protruding length
40 mm
LTA Length tool assembly
40 mm
MTP Clamping type code
P - Hole clamping, with straight bore
Name Identifying order number
12631230386
OAL Overall length
40 mm
STDDES Standard designation
A40B-PDJNL11
THSC Tool holder shape code
A - offset shank design
WF Functional width
47 mm
Working process
DDB - External and internal turning
