Главная Каталог продукции Toolunited 14 309-02 - Turning tool for external threading R356.2020.2.13.IK

R356.2020.2.13.IK

Артикул: R3562020213IK

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HORN - Paul Horn

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/15/2014

DIN CSW1

HORN-31503

FamilyProducts

315 Insert

HAND Cutting direction

R - Right

HF Functional height

25 mm

ID Technical product number

R3562020213IK

Interface codes

Interface codes CSW1

J41 /

ISYC Subclass

309-02 - Turning tool for external threading

LF Functional length

90 mm

LH Head length

30 mm

LOC-03 B Shank width

20 mm

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 H Shank height

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LPR Protruding length

21 mm

Name Identifying order number

R356.2020.2.13.IK

OAL Overall length

90 mm

WF Functional width

17 mm

Working process

DEA - Outer diameter grooving,DGA - Thread turning, external
