Главная Каталог продукции Toolunited 14 309-02 - Turning tool for external threading 12253715200

12253715200

12253715200

12253715200

Widia
Артикул: 12253715200
В наличии
В корзину
Описание
Характеристики
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
WI - Widia
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
98.4 €
DHD Drop head design
2 - Normal and overhead
DIN
VKT10100105
DIN CSW1
WI-123594002
FamilyProducts
Tool holder for thread turning with square-shank
GAMF Rake angle radial
2 Degree
GAMO Rake angle orthogonal
2 Degree
HAND Cutting direction
R - Right
HF Functional height
10 mm
ID Technical product number
12253715200
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-02 - Turning tool for external threading
KAPR Tool cutting edge angle
90 Degree
LAMS Inclination angle
-0.5 Degree
LF Functional length
100 mm
LOC-03 B Shank width
10 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
VKT Square mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
1010
LOC-03 H Shank height
10 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT10100105
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
12253715200
OAL Overall length
100 mm
SX Shank cross section shape code
02 - Square shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
14 mm
Working process
DGA - Thread turning, external
