WWLNR3232-P08
WWLNR3232-P08
Артикул:
1-06-004776
В наличии
Характеристики
A2A Clearance angle major Pos. A
0 Degree
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOR - Korloy
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/4/2014
DIN
VKT32320105
DIN CSW1
WN0804 2L
EPSR Insert included angle
80 Degree
FamilyProducts
Wedge Clamp System
HAND Cutting direction
R - Right
HF Functional height
32 mm
ID Technical product number
1-06-004776
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
95 Degree
L Cutting edge length
8 mm
LF Functional length
170 mm
LH Head length
33 mm
LOC-03 B Shank width
32 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
3232
LOC-03 H Shank height
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT32320105
MIID Master insert identification
WN??0804??
Name Identifying order number
WWLNR3232-P08
OAL Overall length
170 mm
STDDES Standard designation
WWLNR 3232-P08
SX Shank cross section shape code
01 - Square shank
WF Functional width
40 mm
Working process
DDA - External turning,DDB - External and internal turning,DDI - Internal turning
