Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning NKLCRF1212M11Q

NKLCRF1212M11Q

NKLCRF1212M11Q

NKLCRF1212M11Q

Kennametal
Артикул: 1098819
В наличии
В корзину
Описание
Характеристики
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
11/22/2013
DIN
VKT12120105
DIN CSW1
KH-WP TN KCGRRH1103
FamilyProducts
TOOLHOLDER NKLC 95°
GAMF Rake angle radial
0 Degree
GAMO Rake angle orthogonal
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
HF Functional height
12 mm
ID Technical product number
1098819
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
95 Degree
L Cutting edge length
11 mm
LAMS Inclination angle
0 Degree
LF Functional length
150 mm
LH Head length
24 mm
LOC-03 B Shank width
12 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
1212
LOC-03 H Shank height
12 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT12120105
MTP Clamping type code
C - Top clamping without bore
Name Identifying order number
NKLCRF1212M11Q
OAL Overall length
150 mm
SX Shank cross section shape code
01 - Square shank
WF Functional width
12 mm
Working process
DDA - External turning
