Главная Каталог продукции СЗЦПК инструмент 14 309-01 - Tool holder for longitudinal and transversal turning JS25K-TBL3

JS25K-TBL3

JS25K-TBL3 JS25K-TBL3 JS25K-TBL3

JS25K-TBL3

Tungaloy
Артикул: 6821754
В наличии
В корзину
Описание
Характеристики
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
TT - Tungaloy
CXSC Coolant exit style code
0 - Without coolant exit
DCC Design configuration style code
S - Solid steel, no construction features
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/24/2006
DIN
ZYL10002225
DIN CSW1
TT-JTBR3*
FamilyProducts
Toolholder J-series JSxxK-TBL
HAND Cutting direction
L - Left
ID Technical product number
6821754
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
LF Functional length
125 mm
LH Head length
17 mm
LOC-03 B Shank width
12.7 mm
LOC-03 CCFMS Form
22
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03 H Shank height
24 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL10002225
Name Identifying order number
JS25K-TBL3
OAL Overall length
125 mm
SX Shank cross section shape code
31 - (left) Round shank
THSC Tool holder shape code
G - straight shank design
WF Functional width
10 mm
Working process
No working processes available
