Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning E06KSCLDLS4KWH

E06KSCLDLS4KWH

Артикул: E06KSCLDLS4KWH

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN

ZYL00602205

DMIN Minimum bore diameter

7.6 mm

FamilyProducts

Toolholder

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

95 Degree

L Cutting edge length

3.97 mm

LAMS Inclination angle

-1 Degree

LF Functional length

2 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00602205

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

E06KSCLDLS4KWH

OAL Overall length

125 mm

WF Functional width

3.8 mm

Working process

No working processes available
