A50UNVQCR16

Артикул: A50UNVQCR16

В наличии

В корзину

Описание

Характеристики

CEDC Cutting edge count

COMPC Company code

KH - Kennametal

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DIN CSW1

KH-WP TN VCGRTOP NOT

DMIN Minimum bore diameter

63 mm

FamilyProducts

Toolholder

HAND Cutting direction

R - Right

Interface codes

Interface codes CSW1

J41 /

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

107.3 Degree

L Cutting edge length

16 mm

LAMS Inclination angle

-2 Degree

LF Functional length

350 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CZCMS Connection size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

MTP Clamping type code

C - Top clamping without bore

Name Identifying order number

A50UNVQCR16

OAL Overall length

350 mm

WF Functional width

35 mm

Working process

No working processes available
