Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning 1.78025R100

1.78025R100

1.78025R100

1.78025R100

Kennametal
Артикул: 1.78025R100
В наличии
В корзину
Описание
Характеристики
CEATC Tool cutting edge angle type code
S - Side lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
11/22/2013
DIN
VKT25250105
DIN CSW1
KH-C8FIX12-R
EPSR Insert included angle
90 Degree
FamilyProducts
TOOLHOLDER FIXPERFECT 1.7 CUT 8
HAND Cutting direction
R - Right
HF Functional height
25 mm
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
90 Degree
L Cutting edge length
12 mm
LF Functional length
150 mm
LH Head length
26 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
2525
LOC-03 H Shank height
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT25250105
MIID Master insert identification
C8FIX120503RRP
MTP Clamping type code
X - Special mounting type
Name Identifying order number
1.78025R100
OAL Overall length
150 mm
SX Shank cross section shape code
01 - Square shank
WF Functional width
32 mm
Working process
DDA - External turning
