Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning 12156477586

12156477586

12156477586 12156477586

12156477586

Widia
Артикул: 12156477586
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
7 Degree
B3A Inscribed circle diameter Pos. A
9.525 mm
BLDA Tool style code Position A
3
C1A Insert thickness Pos. A
3.97 mm
CEATC Tool cutting edge angle type code
B - Side and front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
WI - Widia
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCC Design configuration style code
A - Solid steel, with internal coolant supply
DCP Data chip provision
0 - Without data chip
Delivery state valid from
160.9 €
DHD Drop head design
2 - Normal and overhead
DIN
ZYL03202215
DIN CSW1
DC11T3 3N
DMIN Minimum bore diameter
40 mm
EPSR Insert included angle
55 Degree
FamilyProducts
Tool holder for boring with cylindrical-shank
GAMF Rake angle radial
-9 Degree
HAND Cutting direction
L - Left
HF Functional height
16 mm
ID Technical product number
12156477586
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
107.5 Degree
L Cutting edge length
11.6 mm
LF Functional length
250 mm
LOC-03 CCFMS Form
22
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03202215
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
12156477586
OAL Overall length
250 mm
STDDES Standard designation
A32S-SDQCL11
SX Shank cross section shape code
10 - Round shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
22 mm
Working process
DDI - Internal turning
