Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning 12153338686

12153338686

12153338686

Widia

Артикул: 12153338686

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

7 Degree

B3A Inscribed circle diameter Pos. A

6.35 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

2.38 mm

CEATC Tool cutting edge angle type code

B - Side and front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCC Design configuration style code

E - Hard metal shank with steel head, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

229.6 €

DHD Drop head design

2 - Normal and overhead

DIN

ZYL01202215

DIN CSW1

DC0702 3N

DMIN Minimum bore diameter

16 mm

EPSR Insert included angle

55 Degree

FamilyProducts

Tool holder for boring with cylindrical-shank

GAMF Rake angle radial

-7 Degree

HAND Cutting direction

R - Right

HF Functional height

6 mm

ID Technical product number

12153338686

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

107.5 Degree

L Cutting edge length

7.75 mm

LF Functional length

180 mm

LOC-03 CCFMS Form

22

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01202215

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

12153338686

OAL Overall length

180 mm

STDDES Standard designation

E12Q-SDQCR07

SX Shank cross section shape code

10 - Round shank

THSC Tool holder shape code

A - offset shank design

WF Functional width

9 mm

Working process

DDI - Internal turning
