Главная Каталог продукции Toolunited 14 309-01 - Tool holder for longitudinal and transversal turning 12055752486

12055752486

12055752486

Widia

Артикул: 12055752486

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

7 Degree

B3A Inscribed circle diameter Pos. A

9.525 mm

BLDA Tool style code Position A

3

C1A Insert thickness Pos. A

3.97 mm

CEATC Tool cutting edge angle type code

S - Side lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

WI - Widia

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

67.1 €

DHD Drop head design

2 - Normal and overhead

DIN

VKT25250105

DIN CSW1

DC11T3 3N

EPSR Insert included angle

55 Degree

FamilyProducts

Tool holder with square-shank for inserts

GAMF Rake angle radial

0 Degree

GAMO Rake angle orthogonal

0 Degree

HAND Cutting direction

N - Neutral

HF Functional height

25 mm

ID Technical product number

12055752486

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-01 - Tool holder for longitudinal and transversal turning

KAPR Tool cutting edge angle

63 Degree

L Cutting edge length

11.6 mm

LAMS Inclination angle

0 Degree

LF Functional length

150 mm

LH Head length

25 mm

LOC-03 B Shank width

25 mm

LOC-03 CCFMS Form

01

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

VKT Square mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

2525

LOC-03 H Shank height

25 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT25250105

MIID Master insert identification

DC..11T308

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

12055752486

OAL Overall length

150 mm

STDDES Standard designation

SDNCN2525M11

SX Shank cross section shape code

01 - Square shank

THSC Tool holder shape code

G - straight shank design

WF Functional width

12.5 mm

Working process

DDA - External turning
