12052611200
12052611200
Артикул:
12052611200
В наличии
Характеристики
A2A Clearance angle major Pos. A
7 Degree
B3A Inscribed circle diameter Pos. A
6.35 mm
BLDA Tool style code Position A
1
C1A Insert thickness Pos. A
2.38 mm
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
WI - Widia
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
55.6 €
DHD Drop head design
2 - Normal and overhead
DIN
VKT12120105
DIN CSW1
TC1102 3N
EPSR Insert included angle
60 Degree
FamilyProducts
Tool holder with square-shank for inserts
GAMF Rake angle radial
0 Degree
GAMO Rake angle orthogonal
0 Degree
HAND Cutting direction
N - Neutral
HF Functional height
12 mm
ID Technical product number
12052611200
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
90 Degree
L Cutting edge length
10.4 mm
LAMS Inclination angle
0 Degree
LF Functional length
80 mm
LH Head length
12 mm
LOC-03 B Shank width
12 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
VKT Square mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
1212
LOC-03 H Shank height
12 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT12120105
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
12052611200
OAL Overall length
80 mm
STDDES Standard designation
STCCN1212F11
SX Shank cross section shape code
01 - Square shank
THSC Tool holder shape code
G - straight shank design
WF Functional width
6 mm
Working process
DDA - External turning
