Главная Каталог продукции Toolunited 14 309-04 - Turning tool for OD grooving and parting RU390.0750.04

RU390.0750.04

RU390.0750.04

RU390.0750.04

Paul Horn
Артикул: RU390075004
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
8 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CW Cutting width
6.299 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/15/2014
DIN
ZYL07502225
DIN CSW1
HORN-31204
FamilyProducts
Toolholder
HAND Cutting direction
R - Right
HF Functional height
25.4 mm
ID Technical product number
RU390075004
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LF Functional length
127 mm
LH Head length
21.996 mm
LOC-03 B Shank width
19.05 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0750
LOC-03 H Shank height
19.05 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL07502225
LPR Protruding length
21.9964 mm
Name Identifying order number
RU390.0750.04
OAL Overall length
127 mm
SX Shank cross section shape code
01 - Square shank
WF Functional width
13.843 mm
Working process
No working processes available
