Главная Каталог продукции Toolunited 14 309-04 - Turning tool for OD grooving and parting RU360.0500.01

RU360.0500.01

RU360.0500.01

RU360.0500.01

Paul Horn
Артикул: RU360050001
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
3.9878 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CW Cutting width
1.88 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/15/2014
DIN
ZYL05002225
DIN CSW1
HORN-31201
FamilyProducts
Toolholder
HAND Cutting direction
R - Right
HF Functional height
25.4 mm
ID Technical product number
RU360050001
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LF Functional length
101.6 mm
LH Head length
23.978 mm
LOC-03 B Shank width
12.7 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0500
LOC-03 H Shank height
12.7 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL05002225
LPR Protruding length
23.9776 mm
Name Identifying order number
RU360.0500.01
OAL Overall length
101.6 mm
SX Shank cross section shape code
01 - Square shank
WF Functional width
11.2014 mm
Working process
No working processes available
