Главная Каталог продукции Toolunited 14 309-04 - Turning tool for OD grooving and parting R218.1616.2.04.IK

R218.1616.2.04.IK

R218.1616.2.04.IK

R218.1616.2.04.IK

Paul Horn
Артикул: R2181616204IK
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
18 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/15/2014
DIN
VKT16160105
DIN CSW1
HORN-22904
FamilyProducts
229 Tool
HAND Cutting direction
R - Right
HF Functional height
25 mm
ID Technical product number
R2181616204IK
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LF Functional length
91 mm
LH Head length
43.5 mm
LOC-03 B Shank width
16 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
1616
LOC-03 H Shank height
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT16160105
LPR Protruding length
37 mm
Name Identifying order number
R218.1616.2.04.IK
OAL Overall length
91 mm
SX Shank cross section shape code
01 - Square shank
WF Functional width
13.7 mm
Working process
DDA - External turning,DEA - Outer diameter grooving
