Главная Каталог продукции Toolunited 14 309-04 - Turning tool for OD grooving and parting A4SML2525M0520

A4SML2525M0520

A4SML2525M0520

A4SML2525M0520

Kennametal
Артикул: 1949648
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
20 mm
CEATC Tool cutting edge angle type code
S - Side lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CW Cutting width
5 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
10/10/2012
DIN
VKT25250105
DIN CSW1
KH-A4-5
FamilyProducts
A4 Stechhalter Kennametal
GAMF Rake angle radial
0 Degree
GAMO Rake angle orthogonal
0 Degree
HAND Cutting direction
L - Left
HF Functional height
33 mm
ID Technical product number
1949648
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LAMS Inclination angle
0 Degree
LF Functional length
150 mm
LH Head length
40 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
2525
LOC-03 H Shank height
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT25250105
Name Identifying order number
A4SML2525M0520
OAL Overall length
150 mm
SX Shank cross section shape code
01 - Square shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
22.72 mm
Working process
No working processes available
