231650 19,4
231650 19,4
Артикул:
231650 19,4
В наличии
Характеристики
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating / Покрытие
TiCN/TiAlN
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
19.4 mm
Delivery state valid from
1/11/2017
DIN
HOG-HPIE190000
FamilyProducts
GARANT HiPer drill cutter insert h7
GRDMFG Grade manufacturers designation
HB7630
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
203-03 - Replaceable insert flatted with chip flute
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HOG-HPIE190000
Name Identifying order number
231650 19,4
NOF Flute count
2
OAL Overall length
17.7 mm
PL Point length
4.02 mm
S1 Insert thickness total
6.8 mm
SIG Point angle 1st step
135 Degree
Working process
BVB - Drilling
