PICCO RX050.6-22R20 IC908
PICCO RX050.6-22R20 IC908
Артикул:
PICCO RX050.6-22R20 IC908
В наличии
Характеристики
CDX Cutting depth maximum
0.4 mm
COMPC Company code
IS - Iscar
Delivery state valid from
8/25/2016
DIN
ZYL00602205
EPSR Insert included angle
77 Degree
FamilyProducts
Reinforced boring inserts with internal coolant holes
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
310-01 - Turning tool No 1 - straight design
LH Head length
22 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0060
LOC-03 DCONMS Diameter
6 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00602205
Name Identifying order number
PICCO RX050.6-22R20 IC908
OAL Overall length
37 mm
TCDCONMS ISO-tolerance class shank diameter
h6
WF Functional width
2.5 mm
WFA A dimension on wf
5.5 mm
Working process
No working processes available
