PICCO RX050.5-25R10 IC908

Артикул: PICCO RX050.5-25R10 IC908

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

0.3 mm

COMPC Company code

IS - Iscar

Delivery state valid from

8/25/2016

DIN

ZYL00502205

EPSR Insert included angle

77 Degree

FamilyProducts

Reinforced boring inserts with internal coolant holes

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

310-01 - Turning tool No 1 - straight design

LH Head length

25 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0050

LOC-03 DCONMS Diameter

5 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00502205

Name Identifying order number

PICCO RX050.5-25R10 IC908

OAL Overall length

40 mm

TCDCONMS ISO-tolerance class shank diameter

WF Functional width

2.1 mm

WFA A dimension on wf

4.6 mm

Working process

No working processes available
