PICCO RX050.4-10R10 IC908
PICCO RX050.4-10R10 IC908
Артикул:
PICCO RX050.4-10R10 IC908
В наличии
Характеристики
CDX Cutting depth maximum
0.2 mm
COMPC Company code
IS - Iscar
Delivery state valid from
8/25/2016
DIN
ZYL00402205
EPSR Insert included angle
77 Degree
FamilyProducts
Reinforced boring inserts with internal coolant holes
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
310-01 - Turning tool No 1 - straight design
LH Head length
10 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00402205
Name Identifying order number
PICCO RX050.4-10R10 IC908
OAL Overall length
24 mm
TCDCONMS ISO-tolerance class shank diameter
h6
WF Functional width
1.6 mm
WFA A dimension on wf
3.6 mm
Working process
No working processes available
