KM63FBHS116150

Артикул: KM63FBHS116150

В наличии

В корзину

Описание

Характеристики

BDX Body diameter maximum

94 mm

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCN Cutting diameter minimum

116 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

153 mm

Delivery state valid from

1/4/2017

DIN

KH-KMMBFFKM63

DIN CSW1

KH-WP CCGX09T3

FamilyProducts

KM SINGLE CUTTER FINE BORING

HAND Cutting direction

R - Right

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

305-18 - Boring head with adjustable unit

LOC-01-Connection-codes

J41 / J441 - Interface code position A (cutting edge) (Unknown 01)

LOC-01-DIN

KH-WP CCGX09T3

LOC-02-Connection-codes

J41 / J441 - Interface code position A (cutting edge) (Unknown 02)

LOC-02-DIN

KH-WP SC CCGT09T3

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0630

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-KMMBFFKM63

LPR Protruding length

150 mm

Name Identifying order number

KM63FBHS116150

RPMX Rotational speed maximum

150 1/min

Working process

No working processes available

WT Weight of item

4.2 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
