Главная Каталог продукции Toolunited 13 305-18 - Boring head with adjustable unit KM50TSFBH065088

KM50TSFBH065088

Артикул: KM50TSFBH065088

В наличии

В корзину

Описание

Характеристики

BDX Body diameter maximum

55 mm

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

WI - Widia

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCN Cutting diameter minimum

65 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

88 mm

Delivery state valid from

2/1/2017

DIN

KMT05000115

DIN CSW1

WI-RFX Schnh 65-88

FamilyProducts

FBH, KM Series Shank

HAND Cutting direction

R - Right

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

305-18 - Boring head with adjustable unit

LOC-01-Connection-codes

J41 / J441 - Interface code position A (cutting edge) (Unknown 01)

LOC-01-DIN

WI-RFX Schnh 65-88

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

KMT KM connection KENNAMETAL / UTS connection WIDIA

LOC-03 CCUMS Unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KMT05000115

LPR Protruding length

130 mm

Name Identifying order number

KM50TSFBH065088

Working process

No working processes available

WT Weight of item

1.7 kg

ZEFP Peripheral effective cutting edge count
