3782 12.000
3782 12.000
Артикул:
3782 12.000
В наличии
Характеристики
APMX Depth of cut maximum
28 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
OHNE
COMPC Company code
GG - Gühring
CRCLMFG Chip removal class mfg
N
CXSC Coolant exit style code
0 - Without coolant exit
DCD Drilling diameter
10.2 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
9.95 mm
Delivery state valid from
1/18/2024
DIN
ZYL01400105
DN Neck diameter
13.5 mm
FamilyProducts
BOHRGEW.FR.DTMC SP
FHA Flute helix angle
27 Degree
FHH Flute helix hand
R - Hand of helix right
FHP Flute helix pitch
61.3 mm
GAMF Rake angle radial
27 Degree
GAMP Rake angle axial
5 Degree
GRD2ND Standard designation of the grade 2nd application
VHM
GRDMFG Grade manufacturers designation
VHM
GRDPRIO Standard designation of the grade main application
HF-K
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
303-11 - Thread end mill with drilling part
LF Functional length
90 mm
LH Head length
31.4 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0140
LOC-03 DCONMS Diameter
14 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01400105
LPR Protruding length
45 mm
LS Shank length
45 mm
MILTTY Mill tool type ISO
T - Thread cutter
Name Identifying order number
3782 12.000
OAL Overall length
90 mm
PRFA Profile included angle
140 Degree
TD Thread diameter
12 mm
THFT Thread form type
M
TP Thread pitch
1.75 mm
Working process
FSB - Thrilling (drilling & threading)
WT Weight of item
0.13 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
