Главная Каталог продукции Toolunited 13 302-02 - Step drill EP0201155

EP0201155

Артикул: EP0201155

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

EgiAs

COMPC Company code

OSG

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

5 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/1/2024

DIN

ZYL00800105

FamilyProducts

HY-PRO D 5x8 (M6x1) HYP-HP-SC-3D

FHA Flute helix angle

40 Degree

FHH Flute helix hand

R - Hand of helix right

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LCF Length chip flute

23 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

LPR Protruding length

28 mm

LS Shank length

51 mm

LU Usable length

20.41 mm

Name Identifying order number

EP0201155

NOF Flute count

NOS Step count

OAL Overall length

79 mm

PL Point length

0.91 mm

SDL Step diameter length

18 mm

SIG Point angle 1st step

140 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling,SPR - Profile counterboring
