DML050V

Артикул: DML050V

В наличии

В корзину

Описание

Характеристики

BMC Body material code

B - Steel body with brazed carbide inserts

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

5 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/14/2010

DIN

ZYL00800105

FamilyProducts

SUMIDIA Diamond step drill DML

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

DA2200

HAND Cutting direction

R - Right

ID Technical product number

DML050V

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LCF Length chip flute

36 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$08

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

Materials

Name Identifying order number

DML050V

NOF Flute count

NOS Step count

OAL Overall length

90 mm

SDL Step diameter length

18 mm

SIG Point angle 1st step

140 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
