Главная Каталог продукции Toolunited 13 302-02 - Step drill B732A12000HP KCPK15

B732A12000HP KCPK15

Артикул: 4175415

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter minimum

12 mm

DCONMSLD Shank diameter lower limit

-0.011 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state

11/19/2015

DIN

ZYL01600115

FamilyProducts

HP-Stufenbohrer, mit Kühlmittelbohrung B732 lang

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

KCPK15

HAND Cutting direction

R - Right

ID Technical product number

4175415

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600115

LS Shank length

48 mm

LU Usable length

44.5 mm

Name Identifying order number

B732A12000HP KCPK15

NOF Flute count

NOS Step count

OAL Overall length

115 mm

PL Point length

2.2 mm

SDL Step diameter length

40 mm

SIG Point angle 1st step

135 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
