Главная Каталог продукции Toolunited 13 302-02 - Step drill B731A19446HP KCPK15

B731A19446HP KCPK15

Артикул: 4175433

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter minimum

19.446 mm

DCONMSLD Shank diameter lower limit

-0.013 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state

11/19/2015

DIN

ZYL02500115

FamilyProducts

HP-Stufenbohrer, mit Kühlmittelbohrung B731 kurz

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

KCPK15

HAND Cutting direction

R - Right

ID Technical product number

4175433

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

25 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02500115

LPR Protruding length

78 mm

LS Shank length

56 mm

LU Usable length

49.9 mm

Name Identifying order number

B731A19446HP KCPK15

NOF Flute count

NOS Step count

OAL Overall length

153 mm

PL Point length

3.6 mm

SDL Step diameter length

43 mm

SIG Point angle 1st step

135 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

BVB - Drilling
