MNC 310-155 A32-175-07-5D

Артикул: 3202866

В наличии

В корзину

Описание

Характеристики

A1B Cutting edge angle major Pos. B

90 Degree

B1B Cutting edge length Pos. B

7.7 mm

B3B Inscribed circle diameter Pos. B

7.7 mm

BLDB Tool style code Position B

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CEDC Cutting edge count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter 1st step maximum

17.5 mm

Delivery state valid from

9/11/2017

DF Flange diameter

42 mm

DIN

ZYL03201115

FamilyProducts

COMBICHAM Indexable Drill, Pilot Drilling Head 5xD

HAND Cutting direction

R - Right

ID Technical product number

3202866

Interface codes

J6 / J61

ISO

ZYL11G3200h$06

ISYC Subclass

306-09 - Step drill for adjustable solid drill

LOC-01 BI Block index

LOC-01 MIID Master insert identification

SOGX070305-W

LOC-01-Connection-codes

J43 / J431 - interface code, workpiece side, for drilling heads or pilot drills

LOC-01-DIN

IS-17,5IC

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL11G3200h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03201115

LPR Protruding length

193.4 mm

LS Shank length

60 mm

LU Usable length

158.4 mm

Name Identifying order number

MNC 310-155 A32-175-07-5D

NUMBER INSERTS OUTSIDE Number of inserts outside

OAL Overall length

253.35 mm

TCDCONMS ISO-tolerance class shank diameter

TL Taper length

3.35 mm

Working process

BVB - Drilling

WT Weight of item

0.91 kg

Максимальный диаметр корпуса (BDX) / Body diameter maximum (BDX)

42 mm
