Главная Каталог продукции Toolunited 13 306-09 - Step drill for adjustable solid drill 3.37071R320

3.37071R320

Артикул: 1191050

В наличии

В корзину

Описание

Характеристики

CCF Connection code form

CCONMS Connection count machine side

CCS Connection code style

CCT Connection code type

ZYL

CCU Connection code unit base

CEDC Cutting edge count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

CZC Connection size code

0070

DCINTF Interference cutting diameter

7 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter 1st step maximum

11.5 mm

Delivery state valid from

5/28/2017

DIN

ZYL02000105

FamilyProducts

METRIC BF BODY, SHANK A (SS)

HAND Cutting direction

R - Right

ID Technical product number

1191050

Interface codes

J6 /

ISYC Subclass

306-09 - Step drill for adjustable solid drill

LOC-01 BI Block index

LOC-01 CCF Connection code form

LOC-01 CCS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCT Connection code type

ZYL cylindrical shank

LOC-01 CCU Connection code unit base

0 Metric

LOC-01 CZC Connection size code

0070

LOC-01 MIID Master insert identification

3.41020..

LOC-01-Connection-codes

J43 / J431 - interface code, workpiece side, for drilling heads or pilot drills

LOC-01-DIN

ZYL00700105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000105

LPR Protruding length

48.1 mm

LS Shank length

50 mm

Name Identifying order number

3.37071R320

NUMBER INSERTS OUTSIDE Number of inserts outside

OAL Overall length

97.3 mm

SIG Point angle 1st step

90 Degree

Working process

No working processes available
