Главная Каталог продукции Toolunited 13 306-01 - Twist drill for indexable inserts V45 72252

V45 72252

V45 72252

Komet Group

Артикул: 1497380

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

84 Degree

A1B Cutting edge angle major Pos. B

84 Degree

A2A Clearance angle major Pos. A

8 Degree

A2B Clearance angle major Pos. B

8 Degree

B1A Cutting edge length Pos. A

4.1 mm

B1B Cutting edge length Pos. B

4.1 mm

B3A Inscribed circle diameter Pos. A

6.35 mm

B3B Inscribed circle diameter Pos. B

6.35 mm

BLDA Tool style code Position A

7

BLDEV Balancing device

0

C1A Insert thickness Pos. A

3.18 mm

C1B Insert thickness Pos. B

3.18 mm

CCONMS Connection count machine side

1

CEDC Cutting edge count

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D6A Wiper edge length Pos. A

4.1 mm

D6B Wiper edge length Pos. B

4.1 mm

DC Cutting diameter minimum

22.5 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DF Flange diameter

39 mm

DIN

ZYL03201415

FamilyProducts

KUB Trigon dia.22,5

HAND Cutting direction

R - Right

ID Technical product number

1497380

Interface codes

J6 /

ISYC Subclass

306-01 - Twist drill for indexable inserts

LCF Length chip flute

89 mm

LOC-03 CCFMS Connection code form

14

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03201415

LPR Protruding length

93 mm

LU Usable length

69 mm

Name Identifying order number

V45 72252

NUMBER INSERTS INSIDE Number of inserts inside

1

NUMBER INSERTS OUTSIDE Number of inserts outside

1

OAL Overall length

153 mm

SIG Point angle 1st step

180 Degree

STDNO Standard

DIN6535HE+DIN6595

Working process

No working processes available
