Главная Каталог продукции Toolunited 13 306-01 - Twist drill for indexable inserts V30 71750

V30 71750

V30 71750 V30 71750 V30 71750

V30 71750

Komet Group
Артикул: 1474788
В наличии
В корзину
Описание
Характеристики
BLDEV Balancing device
0
CCONMS Connection count machine side
0
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter minimum
17.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
FamilyProducts
KUB Trigon dia.17,5 999
HAND Cutting direction
R - Right
ID Technical product number
1474788
Interface codes
/
ISYC Subclass
306-01 - Twist drill for indexable inserts
LCF Length chip flute
59 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ABS KOMET ABS connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 DCONMS Diameter
50 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LPR Protruding length
89 mm
LU Usable length
54 mm
Name Identifying order number
V30 71750
NUMBER INSERTS INSIDE Number of inserts inside
1
NUMBER INSERTS OUTSIDE Number of inserts outside
1
OAL Overall length
120 mm
SIG Point angle 1st step
180 Degree
Working process
No working processes available
WT Weight of item
0.49 kg
